Harden® Double Shaft Shredder - Two Drives - Heavy Duty

Harden® TD/TDH series are heavy-duty double shaft shredder that are suitable to process all kinds of solid waste and gain recognition from customers by its powerful and stable performance. TD series are driven by electrical motors and TDH by hydraulic system. The installed power is range from 60 to 400KW.


Harden® owns several advanced technologies of heavy-duty double shaft shredder, including splined shaft coupling, integrated knife box assembly and so on.


Features of Harden® Double Shaft Shredder

Blades Made in High Strength Alloy

Stable Quality | Wear-Resistant | Never Fracture

Transmission Parts Protection

Dustproof | Grease Isolation Protection | Long Service Life

Hydraulic System

Variable Speed Torque | Automatic Matching

Drawing
Parameter
Model
       TD612
TD912
TDH912 (Hydraulic)
TD1216
TDH1216 (Hydraulic)
Motor Power (KW)
45+45
75+75
75 / 132 / 160  (Hydraulic)
90 +90 / 132+132
200 / 160 *2 (Hydraulic)

      Rotating Speed (RPM)

14-20
11-20
6-16
10-20
7-21
Size of Cutting Chamber (AxB)(mm)
650*1200
900*1200
1200*1600
Machine Dimensions (LxWxH)(mm)
4390*2180*600
5100*2800*3200
4200*1700*3200
5900*3700*3500
4600*2000*3200

  Quantity of Blade (PCS)

40/20
40/20
20
26
Capacity (Ton/Hour)
3~20
3~30 (TD912)
2~9 (TDH912)
10~50 (TD1216)
8~30 (TDH1215)
Application
Hazardous Waste
Household Appliances
Bulky Waste
Tyres
Fabric
Municipal Waste
Medical Waste
Wood Waste
